Suspension Lift Kit w/Shocks; 5 in. Lift; Incl. Lifted N3 Struts; Premium N3 Shocks;
Stout upper strut spacers, a beefy front and rear skid plate, our Heavy Duty Front and Rear Crossmembers, and a set of differential and sway-bar drop brackets - all designed by our in-house Research and Development team with 100% laser-cut materials for the best possible fit on your vehicle. Also included are a set of our Nitrogen charged N3 Shocks! Offering the best in balanced performance for on and off-road use, these shocks feature a 10-stage velocity sensitive valving custom tuned for this specific application. That means these shocks are specifically valved for use with this vehicle and lift combo, giving you unparalleled performance for any driving situation.
- Increased ground clearance
- Maintains factory track width
- Can run factory 20-inch wheels
- Fabricated blocks are stronger and offer a longer lifespan than cast blocks.
Information:
Does NOT fit GMC Denali models with Magnetic Ride Control. Does not fit Hybrid eAssist models If wider than 33x12.50 tires are used, offset wheels will be required and trimming may be required. Requires minor cutting and drilling. If truck is equipped with a mass damper on the front differential, the damper must be removed.
Application Summary:
| Year |
Make/Model |
| 2014-2018 |
Chevrolet Silverado 1500 |
| 2019 |
Chevrolet Silverado 1500 LD |
| 2014-2018 |
GMC Sierra 1500 |
| Attributes |
| California Proposition 65 |
WARNING: Cancer - www.P65Warnings.ca.gov |
| Category |
Susp Lift Kits 4wd |
| Country of Origin (Primary) |
US |
| Front Components |
Lifted struts, Front crossmember, Rear crossmember, Control arm drop brackets, Differential drop brackets, Sway-bar drop brackets, Steering extension, Steering brace, Front skid plate, Lower skid plate, Hardware |
| Front Kit Componenets |
Lifted struts, Front crossmember, Rear crossmember, Control arm drop brackets, Differential drop brackets, Sway-bar drop brackets, Steering extension, Steering brace, Front skid plate, Lower skid plate, Hardware |
| Front Kit Components |
Lifted struts, Front crossmember, Rear crossmember, Control arm drop brackets, Differential drop brackets, Sway-bar drop brackets, Steering extension, Steering brace, Front skid plate, Lower skid plate, Hardware |
| GTIN |
00843030183820 |
| Harmonized Tariff Code (Schedule B) |
8708809900 |
| Hazardous Material Code |
N |
| Install Time |
8-10 hours |
| Life Cycle Status Code |
Available to Order |
| Lift/Drop Height |
5 in. |
| NAFTA Preference Criterion Code |
B |
| Rear Components |
Fabricated lift blocks, Brake line relocation brackets, U-bolts, Hardware |
| Rear Kit Components |
Fabricated lift blocks, Brake line relocation brackets, U-bolts, Hardware |
| SDR Required Flag |
N |
| Shipping Options |
No Restrictions |
| Ships in Multiple Boxes |
Y |
| Tire & Wheel Size Combinations |
305/55 R20 - 20x9, Offset: +12 to +18mm (Models equipped with Factory 18-inch or larger wheels must run 18-inch or larger wheels if changing to aftermarket wheels), 305/55 R20 - 20x9, Offset: +12 to +18mm (Models equipped with Factory 18-inch or larger wheels must run 18-inch or larger wheels if changing to aftermarket wheels) |
| Tire, Wheel, and Offset Info |
295 70R17:Factory 17:6x5.5:-:-; 295 55R20:Factory 20:6x5.5:-:0.25 Spacer; 285 65R18:Factory 18:6x5.5:-:-; 33x12.50R17:17x8.5:6x5.5:+0:-; 285 70R17:17x8.5:6x5.5:+0:-; 33x12.50R17:17x8.5:6x5.5:+1:-; 33x12.50R17:17x9:6x5.5:+0:-; 285 70R17:17x9:6x5.5:+0:-; 33x12.50R17:17x9:6x5.5:+1:-; 285 70R17:17x9:6x5.5:+1:-; 33x12.50R17:17x9:6x5.5:+12:-; 305 70R17:17x9:6x5.5:+12:-; 33x12.50R17:17x9:6x5.5:+18:-; 305 70R17:17x9:6x5.5:+18:-; 285 70R17:17x9:6x5.5:+18:-; 33x12.50R18:18x8.5:6x5.5:+0:-; 33x12.50R18:18x8.5:6x5.5:+1:-; 33x12.50R18:18x9:6x5.5:+0:-; 285 65R18:18x9:6x5.5:+0:-; 33x12.50R18:18x9:6x5.5:+1:-; 285 65R18:18x9:6x5.5:+1:-; 33x12.50R18:18x9:6x5.5:+12:-; 305 65R18:18x9:6x5.5:+12:-; 33x12.50R18:18x9:6x5.5:+18:-; 305 65R18:18x9:6x5.5:+18:-; 285 65R18:18x9:6x5.5:+18:-; 285 65R18:18x9:6x5.5:+19:-; 285 65R18:18x9:6x5.5:+20:-; 33x12.50R20:20x9:6x5.5:+0:-; 305 55R20:20x9:6x5.5:+0:-; 295 60R20:20x9:6x5.5:+0:-; 33x12.50R20:20x9:6x5.5:+1:-; 305 55R20:20x9:6x5.5:+1:-; 295 60R20:20x9:6x5.5:+1:-; 33x12.50R20:20x9:6x5.5:+12:-; 305 55R20:20x9:6x5.5:+12:-; 33x12.50R20:20x9:6x5.5:+18:-; 305 55R20:20x9:6x5.5:+18:-; 295 60R20:20x9:6x5.5:+18:-; 33x12.50R20:20x9:6x5.5:+20:-; 305 55R20:20x9:6x5.5:+20:-; 295 60R20:20x9:6x5.5:+20:-; 295 60R20:20x10:6x5.5:-19:Trimming Required; 295 60R20:20x10:6x5.5:-18:Trimming Required |
