3.5 Inch Lift Kit - Mag-ride - Alu/Cast Steel - GMC Sierra 1500 Denali (14-16)
Gain increased ground clearance and killer, good looks with Rough Country's 3.5in Suspension Lift for GMC Sierra Denali 1500 Pickups equipped with Magnetic Ride Control. This all-inclusive kit comes with several fantastic features - all at a price that'll leave plenty of room for new tires and wheels! Rough Country's 3.5in Denali MagneRide lift comes equipped with a set of differential drop spacers, 3in fabricated rear blocks, and a protective differential skid plate for enhanced durability. This kit also features upper control arms with upgraded Ball Joints by MOOG, the most trusted name in Ball Joint design. Easy to install and easier to maintain than any other joint on the market, the Moog Ball Joint system utilizes two powdered-metal gusher bearings with grease grooves to provide the most durable wear surface available. A sealed boot design with grease-relief valve keeps contaminants out while providing a sealed, serviceable environment. Also included in this kit are a set of fabricated rear blocks. Fabricated blocks are stronger and offer a longer lifespan than cast blocks while being less susceptible to damage and the environment.
- Easy bolt-on installation
- Increased ground clearance
- Can be returned to stock! Differential drops maintain proper axle angle
- Ball joints are pre-installed to ease installation
- Fabricated lift blocks are stronger and offer a longer lifespan than cast blocks.
Information:
ONLY fits GMC Denali models with Magnetic Ride Control. Fits Cast Aluminum and Cast Steel Stock Upper Control Arms Does NOT fit 2016+ models with Stock Stamped Steel upper control arms Requires cutting and grinding New lift block replaces the factory equipped block. If truck is equipped with a mass damper on the front differential, the damper must be removed. Retain your factory wheels with our 0.25" wheel spacers (#1065).
Application Summary:
| Year |
Make/Model |
| 2014-2016 |
GMC Sierra 1500 |
| Attributes |
| California Proposition 65 |
WARNING: Cancer - www.P65Warnings.ca.gov |
| Category |
Susp Lift Kits 4wd |
| Country of Origin (Primary) |
CN |
| Front Components |
Strut spacers, Upper control arms, Upper POM ball joints, Differential drop spacers, Differential skid plate, Hardware |
| Front Kit Componenets |
Strut spacers, Forged upper control arms, Upper POM ball joints, Differential drop spacers, Differential skid plate, Hardware |
| Front Kit Components |
Strut spacers, Forged upper control arms, Upper POM ball joints, Differential drop spacers, Differential skid plate, Hardware |
| GTIN |
00843030175573 |
| Harmonized Tariff Code (Schedule B) |
8708809900 |
| Hazardous Material Code |
N |
| Install Time |
4-5 hours |
| Life Cycle Status Code |
Available to Order |
| Lift/Drop Height |
3.5 in. |
| NAFTA Preference Criterion Code |
B |
| Rear Components |
3in fabricated lift blocks, U-bolts, Hardware |
| Rear Kit Components |
3in fabricated lift blocks, U-bolts, Hardware |
| SDR Required Flag |
N |
| Shipping Options |
No Restrictions |
| Ships in Multiple Boxes |
Y |
| Tire & Wheel Size Combinations |
285/55 R20 - 20x9, Offset: 0 to +18mm, 285/55 R20 - 20x9, Offset: 0 to +18mm |
| Tire, Wheel, and Offset Info |
285 70R17:Factory 17:6x5.5:-:-; 285 65R18:Factory 18:6x5.5:-:-; 285 55R20:Factory 20:6x5.5:-:-; 285 70R17:17x8.5:6x5.5:+0:-; 285 70R17:17x8.5:6x5.5:+1:-; 285 70R17:17x9:6x5.5:+0:-; 285 70R17:17x9:6x5.5:+1:-; 285 70R17:17x9:6x5.5:+12:-; 285 70R17:17x9:6x5.5:+18:-; 285 65R18:18x8.5:6x5.5:+0:-; 285 65R18:18x8.5:6x5.5:+1:-; 285 65R18:18x9:6x5.5:+0:-; 265 65R18:18x9:6x5.5:+0:-; 285 65R18:18x9:6x5.5:+1:-; 265 65R18:18x9:6x5.5:+1:-; 285 65R18:18x9:6x5.5:+12:-; 285 65R18:18x9:6x5.5:+18:-; 265 65R18:18x9:6x5.5:+18:-; 285 65R18:18x9:6x5.5:+19:-; 265 65R18:18x9:6x5.5:+19:-; 285 65R18:18x9:6x5.5:+20:-; 265 65R18:18x9:6x5.5:+20:-; 285 55R20:20x9:6x5.5:+0:-; 285 55R20:20x9:6x5.5:+1:-; 285 55R20:20x9:6x5.5:+12:-; 285 55R20:20x9:6x5.5:+18:-; 285 55R20:20x9:6x5.5:+20:-; 285 45R22:22x10:6x5.5:-19:Minor Trimming |
