2020-2024 GM 2500HD-3500HD 4wd 6.5in. Coilover conversion Suspension Lift System 5.75in. rear block without Overload spring Diesel engine - Fox 2.5 Performance Elite front coil-over Fox 2.0 Performance Series rear shocks
Built for strength performance and increased travel these control arms are ready to bolt-in. The upper arms use 1.5" OD x .120-wall tubular construction with an indexed ball joint cup to correct the ball joint positioning allowing additional down travel and camber adjustment. The new lower control arms are built from high strength steel fully boxed with internally gusseted. At the frame mounting ends are durometer-specific rubber bushings for maintenance-free operation while at the other end a quality greaseable ball joints for smooth quiet operation and superior durability. Arms are finished in a durable black powder coat with a billet aluminum dust cap ready for installation right out of the box.
Built for strength performance and increased travel these control arms are ready to bolt-in. The upper arms use 1.5" OD x .120-wall tubular construction with an indexed ball joint cup to correct the ball joint positioning allowing additional down travel and camber adjustment. The new lower control arms are built from high strength steel fully boxed with internally gusseted. At the frame mounting ends are durometer-specific rubber bushings for maintenance-free operation while at the other end a quality greaseable ball joints for smooth quiet operation and superior durability. Arms are finished in a durable black powder coat with a billet aluminum dust cap ready for installation right out of the box.
- FOX 2.5 coil-overs offer improved damper performance over stock
- DSC Adjuster allows easy high-speed and low-speed compression tuning for optimal performance in any terrain
- Performance UCAs increase strength and allow for more suspension travel
- High Clearance design w/ no torsion bar drop maximizes ground clearance
- Robust steering knuckles maintain ESC system compliance
- HD skid plate system improved offroad protection
- Multipoint differential relocation brackets to secure the front axle and improve CV angles
- Factory Protection Plus drivetrain warranty included
Information:
Coilover coil has a large amount of preload a coil spring compressor must be used to remove the coil from the coilover. Failure to use a coil spring compressor may result in death or injury.Application Summary:
| Year | Make/Model |
|---|---|
| 2020-2025 | Chevrolet Silverado 2500 HD |
| 2020-2025 | Chevrolet Silverado 3500 HD |
| 2020-2025 | GMC Sierra 2500 HD |
| 2020-2025 | GMC Sierra 3500 HD |
This item is a package with the following components:
| Attributes | |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Country of Origin (Primary) | US |
| Front Lift Height | 6_5 |
| Front Lift Method | Coil Over |
| GTIN | 00840416420883 |
| Hazardous Material Code | N |
| Installation Difficulty | difficult |
| Installation Time | 9.5 Hrs |
| Life Cycle Status Code | Available to Order |
| NAFTA Preference Criterion Code | B |
| Rear Lift Height | 5 |
| Rear Lift Method | Block |
| Rear Lift Option | Block Kit Without Factory Overload |
| Rear Shock Option | FOX 2 0 Performance Series |
| SDR Required Flag | N |
| Shocks Included | Yes |
NEW! BDS Suspension BDS753FPE 2020-2023 GM 2500HD/3500HD| 4wd| 6.5in. Coilover Suspension Lift System
Product Information
- Brand: BDS Suspension
- Product Number: BDS753FPE
This item is a package with the following components: FOX98224767
